Aerogel insulation board
Aerogel insulation board is a rigid, high-efficiency thermal material made from silica aerogel and special fibers. It offers ultra-low thermal conductivity and high temperature resistance, ideal for building insulation and industrial equipment.
- 650-1500
Классификация Температура (℃)
- 200-300
Насыпная плотность (кг/м³)
- 1.2-1.5
Tensile strength (MPa)/(≥)
- 99%
Hydrophobicity (≥)
Kerui Aerogel insulation board Technical Data Sheet
| Product Specifications | ThermPanel HT650 Aerogel insulation board | ThermPanel SHT1300 Aerogel insulation board | ThermPanel SHT1500 Aerogel insulation board |
|---|---|---|---|
| Thermal conductivity | ≤0.019W/(m·K)(25℃) | ≤0.022W/(m·K)(25℃) | ≤0.024W/(m·K)(25℃) |
| Operating temperature range | 650℃ | 1300℃ | 1500℃ |
| Density | 200~280 kg/m3 | 200~280 kg/m3 | 200~300 kg/m3 |
| Tensile strength | ≥1.5 MPa | ≥1.2 MPa | ≥1.4 MPa |
| Hydrophobicity | ≥99％ | ||
| Flame retardant grade | Level A1 | ||
Description of Aerogel insulation board
Aerogel insulation board is a rigid, high-efficiency thermal insulation board. The material combines silica aerogel with special fibers to produce a rigid nanopore insulation board with ultra-low thermal conductivity and high temperature resistance. It is suitable for integrated insulation boards in building construction and medium and high temperature industrial equipment.
Excellent thermal insulation effect.
Excellent thermal insulation effect.
Excellent compressive and tensile strength.
excellent compressive and tensile strength.
