セラミック・ファイバー・モジュール

Ceramic Fibre Modules are made by folding or cutting ceramic fibre blankets and processed with specialized equipment. They offer reliable quality, easy installation, and excellent heat insulation, suitable for lining various thermal equipment.

1260-1430
分類温度 (℃)
160-2200
かさ密度 (kg/m³)

価格を得るメール送信

Kerui Ceramic Fibre Module Technical Data Sheet

Item/Grade		STD MODULE	HP MODULE	HA MODULE	HZ MODULE
Classification Temperature/℃		1260	1260	1350	1430
Chemical Composition	ω (Al2O3) ≥/%	43	44	52	35
	ω (SiO2) ≥/%	54	55	47	49
	ω (ZrO2) ≥/%	/	/	/	15
カラー		White	White	White	White
かさ密度 (kg/m³)		160-220	160-220	160-220	160-220
Permanent Linear Change ≤/%		1000℃*24h 2.5	1100℃*24h 2.5	1200℃*24h 3.0	1350℃*24h 3.0
Thermal Conductivity Coefficient/[W/(m·K)]	400℃	0.1	0.1	0.1	0.1
	600℃	0.18	0.17	0.16	0.15
	800℃	0.2	0.2	0.2	0.19
	1000℃	0.27	0.26	0.26	0.26

価格

Description of Ceramic Fibre Module

Ceramic Fibre Modules are made by experienced craftsmen by folding ceramic fibre blankets or cutting blocks into layers and processing them with specialised equipment. It has the characteristics of reliable quality, quick installation and superior heat preservation performance. It can be applied to the lining of various thermal equipment.

Low bulk density, lowthermalconductivity.

Excellent thermal shock resistance.

Excellent elasticity and good overall performance.

Easy to install. Good insulation effect.
