Bio Soluble Fiber Cotton for Sale

Bio-soluble fiber cotton is made from a spun and blown technique, with a fluffy appearance. It has low thermal conductivity and good heat resistance.

1000
Max·Service Temperature (℃)
≤2.0
(24h)Linear shrinkage (After burning/24h/1000℃) (%)
90
かさ密度 (kg/m³)
20
Standard size (kg/bag)

価格を得るメール送信

Kerui Bio Soluble Fiber Cotton Technical Data Sheet

Soluble Fiber Products		KR-AEF-BF(Bulk)	KR-AEF-RB (Blanket)	KR-AEF-RM (Module)	KR-AEF-RBD(Board)	KR-AEF-RP(Paper)
Max·Service Temperature		1000	1000	1000	1000	1000
（KG/m3） Density		-	96/128/160	172/192/220	250/280/300	180/200
(24h)Linear shrinkage（After burning）		≤2.0	≤2.0	≤2.0	≤3.0	≤4.0
(24h)Linear shrinkage（After burning）		（1000℃）	（1000℃）	（1000℃）	（1000℃）	（1000℃)
(W/m.k)Thermal Conductivity Rate	Density	90KG/M3	128KG/M3	192KG/M3	300KG/M3	200KG/M3
	400℃	-	0.11	0.15	0.09	0.08
	600℃	-	0.2	0.24	0.12	0.12
	800℃	-	0.31	0.38	0.18	0.18
Chemical Composition（After burning）	SiO2	63-70	63-70	63-70	62-68	62-68
	CaO	25-30	25-30	25-30	22-28	22-28
	MgO	3-8	3-8	3-8	2-6	2-6
	Others	≤2.0	≤2.0	≤2.0	≤3.0	≤3.0
（mm） Standard size		20kg/bag	7200/360061020-50	600/300*150-300	100060020-50	610/1220*0.5-6
Package		Cartons or woven bags		Cartons or Pallets		Cartons
Recommended using temperature: In oxidizing or neutral atmosphere, 100 ~250℃ lower than the maximum service temperature, In reductive atmosphere, 200 ~350℃ lower than the maximum service temperature.

価格

Description of Bio Soluble Fiber Cotton

Bio-soluble fiber cotton is made from a spun and blown technique, the bulk fiber has a fluffy, choppy and fluffy appearance. It is composed of calcium, magnesium and silicate with a low thermal conductivity which gives it very good heat resistance. Bulk fiber is a versatile material commonly used by manufacturers of insulation products and is ideally suited for conversion into vacuum cast panels, liners and form parts.

Low thermal conductivity

Good heat resistance

Versatile for insulation products

Suitable for vacuum cast panels
